68
0: Invalid
1: In running
2: Frequency reached
3: In fault
4: Zero-speed
5: Frequency 1 reached
6: Frequency 2 reached
7: Accelerating
8: Decelerating
9: Under voltage
10: Timer 1 reached
11: Timer 2 reached
12: Indication for completion of phase
13: Indication for completion of procedure
14: PID upper limit
15: PID lower limit
16: 4-20mA cable open
17: Overload
18: Over torque
26: Winding function complete
27: Counter reached
28: Intermediate counter reached
29,constant pressure water supply
Setting
List
0: Invalid
Set as invalid terminal, prevent false operation.
1.In running
Terminal is defined to be in running, when inverter is output, this terminal is ON.
2.Frequency reached
When frequency arrives at setting value, this contact is ON
3.In fault
When inverter detects abnormal existing, this contact is ON.
4.Zero-speed
When frequency output by inverter is less than start-up frequency, this contact
is ON.
5.Frequency 1 reached
6.frequency 2 reached
When frequency arrives at setting value, this contact is ON
6
Chapter 6 Description of parameter setting
FC100 Series User Manaul
