JCM RBA-40C User Manual

Section 2 RBA-40C™ Banknote Acceptor Specifications
Issue #4119-IGE-01-00 © 2020, JAPAN CASH MACHINE CO., LTD.
6
2 SPECIFICATIONS
This section provides specifications of the RBA-40C™ Series Banknote Acceptor (RBA-40C).
Technical Specifications
Table 4 RBA-40C Technical Specifications
Acceptance Rate
*
:
*. The Banknotes accepted on the second attempt are included. The Acceptance Rate Test was conducted on more than 100 Banknotes. The Acceptance Rate may not be true
for the security-hardened Unit (against the counterfeit notes). Refer to the specific Country’s “Software Information Sheet” for each Country’s particular Banknote acceptance
rate.
99% or greater
The following banknote types are excluded:
• Banknotes with excess or poor magnetism or unclear graphics
• Double (dual) Notes
• Worn, dirty, wet, stained, torn or excessively wrinkled Banknotes
• Banknotes having folded corners or edges
• Banknotes having the wrong cut dimensions or printing displacement
• Returned Banknotes because of incorrect or failed insertion.
Banknote Types Accepted
†
:
†. Refer to the “Software Information Sheet” for more details.
• Long side: 110-181mm (4.33-7.12 in.)
• Short side: 60-85mm (2.36-3.34 in.)
Insertion Direction
†
:
Banknote: Four-way
Barcode Ticket: Four-way
Barcode Ticket
‡
:
‡. Refer to the “Barcode Ticket Specification” for more details.
1D Barcode
• Read code interleaved: 2 of 5
• Narrow Bar: 0.5-0.6mm (0.019-0.023 in.)
• Wide Bar to Narrow Bar ratio = 3:1
• Characters: 18 Characters
• Print Position: Middle (Divides a Ticket equally from the left, right, top and bot-
tom of the Ticket’s center
• Print Width: Wider than 10mm (0.39 in.)
2D Barcode
• Format: QR Code
• Variant: Model 2
• Version: 1 - 3
• Error Correction: Level H (Highest)
• Encoding: Numeric, alphanumeric
• Module Size: Minimum 1mm
Processing Speed
**
:
**. Excluding Host Communication time lag.
Approximately 1.8 seconds
(from Banknote insertion to sending Vend Signal)
Escrow: 1 Note
Validation Method:
CIS
Magnetic Sensor (Optional)
Anti-stringing Mechanism: Pull-Back (PB) Unit (Anti-Pullback System - JCM Patented)
Diagnostic Indicators:
Green Status LED
Red Status LED
Interface:
TTL Serial Interface
USB (USB Specification Rev. 2.0 Compliance) (Full Speed/12Mbps)
