Section 7 RBA-40C™ Banknote Acceptor Operational Flowcharts
Issue #4119-IGE-01-00 © 2020, JAPAN CASH MACHINE CO., LTD.
20
Validation Flowchart
Figure 14 depicts a typical RBA-40C Banknote Validation flow process.
Figure 14 RBA-40C Validation Flowchart
Figure 14 RBA-40C Validation Flowchart
a) Is the Banknote authentic?
b) Is the denomination acceptable?
d) Transporting the Banknote
g) Stop operation (Abnormal Signal Output) (*1)
A) From “Initialization and Banknote Acceptance”
Flowchart (Figure 13)
c) Return the Banknote
e) Discharge the Banknote?
f) Is the Banknote returnable?
B) To “Discharging” Flowchart (Figure 15)
*1). When an abnormal signal is received, remove and reapply Power to the RBA-40C Unit after resolving the problem, or send
a RESET Command from the Host Machine.
b
c
d
B
YES
NO
a
e
f
h
YES
NO
YES
A
NO
YES
g
NO
h) Return the Banknote
