JCM RBA-40C User Manual

Issue #4119-IGE-01-00 © 2020, JAPAN CASH MACHINE CO., LTD.
8
Section 3 RBA-40C™ Banknote Acceptor Installation
3 INSTALLATION
This section provides the installation and operating
instructions for the RBA-40C™ Series Banknote
Acceptor (RBA-40C). It includes the following
information:
• DIP Switch Settings
DIP Switch Settings
SW1 (DIP Switch Block 1)
The acceptable denominations can be configured
by SW1.
SW2 (DIP Switch Block 2)
The interface and functions can be configured by
SW2.
Table 8 SW1 (DIP Switch Block 1) Settings
Switch No. ON/OFF Description
1
ON
VEND 1 INHIBIT
OFF VEND 1 ACCEPT
2
ON
VEND 2 INHIBIT
OFF VEND 2 ACCEPT
3
ON VEND 3 INHIBIT
OFF VEND 3 ACCEPT
4
ON VEND 4 INHIBIT
OFF VEND 4 ACCEPT
5
ON
VEND 5 INHIBIT
OFF VEND 5 ACCEPT
6
ON VEND 6 INHIBIT
OFF VEND 6 ACCEPT
7
ON VEND 7 INHIBIT
OFF VEND 7 ACCEPT
8
OFF
*
*. Never Switched to ON.
OFF (Fixed)
ON
12345678
SW1
Table 9 SW2 (DIP Switch Block 2) Settings
Switch
No.
ON/OFF Description
1
ON
Anti-Pullback System: Enable
OFF Anti-Pullback System: Disable
2OFF Reserved
3
ON
Return a detected note upon power up
*
*. Limited to ID-064GD.
OFF
Notify a Host of the note detection upon
power up
*
4OFF Reserved
5
ON Barcode Ticket Acceptance: Enable
OFF Barcode Ticket Acceptance: Disable
6
ON Check Mode-bit: Disable
OFF Check Mode-bit: Enable
7OFF Reserved
8
ON
Pause Dispensing: Enable
*
OFF
Pause Dispensing: Disable
*
ON
12345678
SW2
