Connector Pin Assignment RBA-40C™ Banknote Acceptor Section 4

Bezel Connector Pin Assignment

Table 12 RBA-40C Bezel Connector Pin Assignments

Header: S7B-ZR-3.4 (JST)

Housing: ZHR-7 (JST)

Contact: SZH-002T-P0.5 (MOLEX)

Recommended Wire: UL1061 AWG#26-28

Pin No. Signal Name I/O Function

1 +12V - +12V DC Power Supply

2 GND - GND

3 BZLED_1 - LED Drive Line (Cathode)

4 BZLED_2 - LED Drive Line (Cathode)

5 BZLED_3 - LED Drive Line (Cathode)

6 BZLED_4 - LED Drive Line (Cathode)

7 NC - No Connection

Front View
