GAS HEAT
These gas-fired heaters have aluminized-steel or
optional stainless steel, tubular heat exchangers with
spark ignition with proven pilot.
All gas heaters are shipped from the factory equipped
for natural gas use. See Gas Heat Application Data
Table.
For natural gas heating installations in locations requir-
ing low NOx emissions, Accessory model 1LN0406
must be used.
NOTE: Gas Heaters are shipped available for natural gas, but can be converted to L.P. with Kit Model No. 1NP0440 or 1NP0485 (2
Stage). All furnaces meet the latest California seasonal efficiency requirements.
1. Based on 1075 Btu/Ft
3
.
2. The air flow must be adjusted to obtain a temperature rise within the range shown.
TABLE 3: ELECTRIC HEATER CFM LIMITATIONS
Size
(Tons)
Voltage
Minimum Supply Air (CFM)
Heater kW
5 7 10 15 20 30
3
208/230-1-60 900 900 900 900 900 -
208/230-3-60 900 900 900 900 900 -
460-3-60 - 900 900 900 900 -
600-3-60 - - 900 900 900 -
4
208/230-1-60 1200 1200 1200 1200 1200 -
208/230-3-60 1200 1200 1200 1200 1200 -
460-3-60 - 1200 1200 1200 1200 -
600-3-60 - - 1200 1200 1200 -
5
208/230-1-60 1500 1500 1500 1500 1500 1500
208/230-3-60 1500 1500 1500 1500 1500 1500
460-3-60 - 1500 1500 1500 1500 1500
600-3-60 - - 1500 1500 1500 1500
TABLE 4: GAS HEAT APPLICATION DATA
GAS HEAT
OPTION
INPUT
CAPACITY
(MBH)
OUTPUT
CAPACITY
(MBH)
AVAILABLE
ON MODELS
GAS RATE
1
(FT
3
/HR)
TEMPERATURE RISE °F AT FULL INPUT
2
MIN. MAX.
N05 50 40 3 TON 47 15 45
N07 75 60 4 TON 70 25 70
N11 100 80 3/5/6 TON 93 45/25/25 75/55/55
N13 125 100 4/5/6 TON 116 45/35/30 75/75/75
D07 75 61 3/4/5/6 TON 70 35/25/20/15 70/70/55/45
D13 115 92 3 TON 107 55 90
D13 125 101 4/5/6 TON 116 45/35/30 75/75/75
