Johnson Controls DW-03 - Electrical Data - Dw-03, -04 & -05 Direct Drive W;Powered Convenience Outlet

362247-BIM-B-0109
Johnson Controls Unitary Products 27
TABLE 13:ELECTRICAL DATA - DW-03, -04 & -05 DIRECT DRIVE W/POWERED CONVENIENCE OUTLET
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
-03
(3.0)
208-1-60 11.3 68.0 17.5 2.3 6.0 10.0
None - - - 32.4 40
E05 4.0 1 19.2 44.0 45
E07 5.6 1 26.9 53.7 60
E10 8.0 1 38.5 68.1 70
E15 11.9 2 57.2 91.5 100
E20 15.9 2 76.4 115.6 125
230-1-60 11.3 68.0 17.5 2.3 6.0 10.0
None - - - 32.4 40
E05 5.3 1 23.0 47.6 50
E07 7.5 1 32.6 59.1 60
E10 10.6 1 46.1 75.2 80
E15 15.9 2 69.1 102.8 110
E20 21.2 2 92.2 130.4 150
208-3-60 8.3 68.0 13.0 2.3 6.0 10.0
None - - - 29.1 35
E05 4.0 1 11.1 33.9 35
E07 5.6 1 15.5 39.4 40
E10 8.0 1 22.2 47.8 50
E15 11.9 2 33.0 61.3 70
E20 15.9 2 44.1 75.2 80
230-3-60 8.3 68.0 13.0 2.3 6.0 10.0
None - - - 29.1 35
E05 5.3 1 13.3 35.9 40
E07 7.5 1 18.8 42.6 45
E10 10.6 1 26.6 51.9 60
E15 15.9 2 39.9 67.8 70
E20 21.2 2 53.2 83.7 90
-04
(4.0)
208-1-60 15.4 86.0 24.0 2.3 7.6 10.0
None - - - 39.1 50
E05 4.0 1 19.2 46.0 50
E07 5.6 1 26.9 55.7 60
E10 8.0 1 38.5 70.1 80
E15 11.9 2 57.2 93.5 100
E20 15.9 2 76.4 117.6 125
230-1-60 15.4 86.0 24.0 2.3 7.6 10.0
None - - - 39.1 50
E05 5.3 1 23.0 49.6 50
E07 7.5 1 32.6 61.1 70
E10 10.6 1 46.1 77.2 80
E15 15.9 2 69.1 104.8 110
E20 21.2 2 92.2 132.4 150
208-3-60 11.5 84.0 18.0 2.3 7.6 10.0
None - - - 34.3 45
E05 4.0 1 11.1 35.9 45
E07 5.6 1 15.5 41.4 45
E10 8.0 1 22.2 49.8 50
E15 11.9 2 33.0 63.3 70
E20 15.9 2 44.1 77.2 80
230-3-60 11.5 84.0 18.0 2.3 7.6 10.0
None - - - 34.3 45
E05 5.3 1 13.3 37.9 45
E07 7.5 1 18.8 44.6 45
E10 10.6 1 26.6 53.9 60
E15 15.9 2 39.9 69.8 70
E20 21.2 2 53.2 85.7 90
