Johnson Controls DW-03 - Dw Physical Data; Dw Operating Weights (Lbs.)

362247-BIM-B-0109
20 Johnson Controls Unitary Products
TABLE 8: DW PHYSICAL DATA
MODELS
DW
-03 -04 -05
EVAPORATOR
BLOWER
Centrifugal Blower (Dia. x Wd. in.) 12 X 10 12 X 10 12 X 10
Fan Motor HP (Direct Drive) 3/4 1 1
Fan Motor HP (Belt Drive) 1 1/2 1 1/2 1 1/2
Fan Motor HP (Belt Drive High Static) 1 1/2 1 1/2 2
EVAPORATOR
COIL
Rows Deep 3 4 4
Fins Per Inch 13 13 13
Face Area (Ft.
2
) 5.1 5.1 5.1
CONDENSER
FANS
Propeller Dia. (in.) 24 24 24
Fan Motor HP 1/2 1/2 1/2
Nom. CFM 4200 4200 4200
CONDENSER
COILS
Rows Deep 2 2 2
Fins Per Inch 18 18 18
Face Area (Ft.
2
) 17.117.117.1
COMPRESSOR
Quantity 1 1 1
Type Recip. Recip. Scroll
AIR
FILTERS
Quantity Per Unit (15” X 20” X 1” or 2“) 2 2 2
Quantity Per Unit (14” X 25” X 1” or 2“) 1 1 1
Total Face Area (Ft.
2
) 6.3 6.3 6.3
CHARGE
Refrigerant 22 (lbs./oz.) 9/4 9/8 11/8
TABLE 9: DW OPERATING WEIGHTS (LBS.)
MODEL SIZE 3 TON 4 TON 5 TON
BASIC
UNIT
DW (Cooling Only) 575 585 590
DW
(Gas/Electric)
N05 615 - -
N07 - 635 -
N11 635 - 650
N13 - 655 660
D07 625 635 640
D13 645 655 660
OPTIONS
Economizer 50
Motorized Damper 26
Electric Heater
5 - 7 kW 18
10 - 15 kW 23
20 - 30 kW 28
ACCY.
Roof Curb 92
Barometric Relief / Fixed Air Damper 10
