TABLE 15:ELECTRICAL DATA - DW-03, -04 & -05 BELT DRIVE HIGH STATIC WITH POWERED CONVENIENCE
OUTLET
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
-03
(3.0)
208-1-60 11.3 68.0 17.5 2.3 7.6 10.0
None - - - 34.0 45
E05 4.0 1 19.2 46.0 50
E07 5.6 1 26.9 55.7 60
E10 8.0 1 38.5 70.1 80
E15 11.9 2 57.2 93.5 100
E20 15.9 2 76.4 117.6 125
230-1-60 11.3 68.0 17.5 2.3 7.6 10.0
None - - - 34.0 45
E05 5.3 1 23.0 49.6 50
E07 7.5 1 32.6 61.1 70
E10 10.6 1 46.1 77.2 80
E15 15.9 2 69.1 104.8 110
E20 21.2 2 92.2 132.4 150
208-3-60 8.3 68.0 13.0 2.3 5.2 10.0
None - - - 28.3 35
E05 4.0 1 11.1 32.9 35
E07 5.6 1 15.5 38.4 40
E10 8.0 1 22.2 46.8 50
E15 11.9 2 33.0 60.3 70
E20 15.9 2 44.1 74.2 80
230-3-60 8.3 68.0 13.0 2.3 5.2 10.0
None - - - 28.3 35
E05 5.3 1 13.3 34.9 40
E07 7.5 1 18.8 41.6 45
E10 10.6 1 26.6 50.9 60
E15 15.9 2 39.9 66.8 70
E20 21.2 2 53.2 82.7 90
460-3-60 5.1 34.0 8.0 1.3 2.6 5.0
None - - - 15.3 20
E07 6.8 1 8.5 19.7 20
E10 10.1 1 12.7 24.7 25
E15 13.6 2 17.1 29.9 30
E20 19.5 2 24.5 38.8 40
575-3-60 3.2 26.0 5.0 1.3 2.0 4.0
None - - - 11.2 15
E10 10.6 1 10.6 20.2 25
E15 15.9 1 16.0 26.6 30
E20 21.2 2 21.3 33.0 35
-04
(4.0)
208-1-60 15.4 86.0 24.0 2.3 7.6 10.0
None - - - 39.1 50
E05 4.0 1 19.2 46.0 50
E07 5.6 1 26.9 55.7 60
E10 8.0 1 38.5 70.1 80
E15 11.9 2 57.2 93.5 100
E20 15.9 2 76.4 117.6 125
230-1-60 15.4 86.0 24.0 2.3 7.6 10.0
None - - - 39.1 50
E05 5.3 1 23.0 49.6 50
E07 7.5 1 32.6 61.1 70
E10 10.6 1 46.1 77.2 80
E15 15.9 2 69.1 104.8 110
E20 21.2 2 92.2 132.4 150
208-3-60 11.5 84.0 18.0 2.3 5.2 10.0
None - - - 31.9 40
E05 4.0 1 11.1 32.9 40
E07 5.6 1 15.5 38.4 40
E10 8.0 1 22.2 46.8 50
E15 11.9 2 33.0 60.3 70
E20 15.9 2 44.1 74.2 80
230-3-60 11.5 84.0 18.0 2.3 5.2 10.0
None - - - 31.9 40
E05 5.3 1 13.3 34.9 40
E07 7.5 1 18.8 41.6 45
E10 10.6 1 26.6 50.9 60
E15 15.9 2 39.9 66.8 70
E20 21.2 2 53.2 82.7 90
460-3-60 5.8 42.0 9.0 1.3 2.6 5.0
None - - - 16.1 20
E07 6.8 1 8.5 19.7 20
E10 10.1 1 12.7 24.7 25
E15 13.6 2 17.1 29.9 30
E20 19.5 2 24.5 38.8 40
575-3-60 5.1 34.0 8.0 1.3 2.0 4.0
None - - - 13.4 15
E10 10.6 1 10.6 20.2 25
E15 15.9 1 16.0 26.6 30
E20 21.2 2 21.3 33.0 35
