Johnson Controls DW-03 - Electrical Data - Dw-03, -04 & -05 Direct Drive W;O Powered Convenience Outlet

362247-BIM-B-0109
Johnson Controls Unitary Products 21
TABLE 10:ELECTRICAL DATA - DW-03, -04 & -05 DIRECT DRIVE W/O POWERED CONVENIENCE OUTLET
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
Max
Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
-03
(3.0)
208-1-60 11.3 68.0 17.5 2.3 6.0 0.0
None - - - 22.4 30
E05 4.0 1 19.2 31.5 35
E07 5.6 1 26.9 41.2 45
E10 8.0 1 38.5 55.6 60
E15 11.9 2 57.2 79.0 80
E20 15.9 2 76.4 103.1 110
230-1-60 11.3 68.0 17.5 2.3 6.0 0.0
None - - - 22.4 30
E05 5.3 1 23.0 35.1 40
E07 7.5 1 32.6 46.6 50
E10 10.6 1 46.1 62.7 70
E15 15.9 2 69.1 90.3 100
E20 21.2 2 92.2 117.9 125
208-3-60 8.3 68.0 13.0 2.3 6.0 0.0
None - - - 18.7 25
E05 4.0 1 11.1 21.4 25
E07 5.6 1 15.5 26.9 30
E10 8.0 1 22.2 35.3 40
E15 11.9 2 33.0 48.8 50
E20 15.9 2 44.1 62.7 70
230-3-60 8.3 68.0 13.0 2.3 6.0 0.0
None - - - 18.7 25
E05 5.3 1 13.3 23.4 25
E07 7.5 1 18.8 30.1 35
E10 10.6 1 26.6 39.4 40
E15 15.9 2 39.9 55.3 60
E20 21.2 2 53.2 71.2 80
-04
(4.0)
208-1-60 15.4 86.0 24.0 2.3 7.6 0.0
None - - - 29.1 35
E05 4.0 1 19.2 33.5 40
E07 5.6 1 26.9 43.2 45
E10 8.0 1 38.5 57.6 60
E15 11.9 2 57.2 81.0 90
E20 15.9 2 76.4 105.1 110
230-1-60 15.4 86.0 24.0 2.3 7.6 0.0
None - - - 29.1 35
E05 5.3 1 23.0 37.1 40
E07 7.5 1 32.6 48.6 50
E10 10.6 1 46.1 64.7 70
E15 15.9 2 69.1 92.3 100
E20 21.2 2 92.2 119.9 125
208-3-60 11.5 84.0 18.0 2.3 7.6 0.0
None - - - 24.3 30
E05 4.0 1 11.1 24.3 30
E07 5.6 1 15.5 28.9 35
E10 8.0 1 22.2 37.3 40
E15 11.9 2 33.0 50.8 60
E20 15.9 2 44.1 64.7 70
230-3-60 11.5 84.0 18.0 2.3 7.6 0.0
None - - - 24.3 30
E05 5.3 1 13.3 25.4 35
E07 7.5 1 18.8 32.1 35
E10 10.6 1 26.6 41.4 45
E15 15.9 2 39.9 57.3 60
E20 21.2 2 53.2 73.2 80
