6.9.10.12 Exception to Setting of Run/Stop Operation
This function is used as an exception to the command: “All Groups Run/Stop” and “Run/Stop by Block” op-
erations for those selected Groups or Blocks.
Selecting Exception Settings for the Run/Stop Operation (All Groups/Block) are available as follows.
Ɣ Run and Stop
Ɣ Run
Ɣ Stop
Set by Monitor 1 or 2 > Menu > Service Menu > Exception Setting Run/Stop Operation.
Refer to Section 6.9.11.5 for details.
6.9.10.13 External Input/Output Setting
The external input/output of each of two terminals are optional.
Their assigned functions are shown below.
Set by Monitor 1 or 2 > Menu > Service Menu > External Input/Output Setting.
Refer to Section 6.9.11.6 for details.
Input and Output Connection Function
Input 1 TB3 1-5 Pin
*All Run/Stop (Level) *Emergency Stop (Level)
*All Run (Pulse) *Demand Function (Input 1
only)
*All Stop (Pulse) *No Setting (Factory Setting)
Input 2 TB3 2-5 Pin
Input 3 TB3 3-5 Pin
Input 4 TB3 4-5 Pin
Output 1 TB3 6-8 Pin
*All Run
*All Alarm
*No Setting (Factory Setting)
Output 2 TB3 7-8 Pin
Ŷ([WHUQDO,QSXW)XQFWLRQ
1. All Run/Stop (Level)
All groups simultaneously execute the Run/Stop operation by way of the external input signal.
2. All Run (Pulse)
All groups simultaneously execute the Run operation by way of an external input signal.
3. All Stop (Pulse)
All groups simultaneously Stop operation by the external pulse signal input
4. Emergency Stop (Level)
All groups simultaneously execute the Stop operation by way of an external emergency stop signal.
While “Emergency Stop” is performed, the wired controller LCD displays “Central Control” and
the operation can not be controlled from the wired controller.
Ɣ When in use with other large central controllers, the “Run/Stop” operation is available from other
large central controllers even if it is during an emergency stop.
Ɣ Do not set Emergency Stop when using simultaneously with other central controllers.
• None of the “All Run/Stop” and “Run/Stop by Block” commands will be affected when they are set to the
groups/blocks. However, these commands are accepted as follows even if this function is set.
Ɠ Scheduled Timer Operation
Ɠ “All Run/Stop” and “Run/Stop by Block” by External Input command
• The “Run/Stop” operation is available when the group is selected individually.
To Next Page
