Johnson Controls HIDH018B21S User Manual

CONTROL SYSTEM
TC-15001-rev.3
6-131
6.9.11.5 Exception Setting of Run/Stop Operation
1. Select “Exception Setting Run/Stop
Operation” on the “Service Menu”
screen.
2. Select the operation button for
exception.
Ɣ The selected button is trimmed with
an orange outline.
NOTE:
None of the operation buttons have
factory settings.
3. Touch “Next”.
NOTE:
When the exception operation is not
set, “Next” cannot be selected.
4. Select the exception operation target
(group/block).
Ɣ Touch the Group button to switch
back and forth between
“Select”
“Cancel”.
Ɣ Touch the Block button to switch
back and forth between
“Select”
“Cancel” of all groups
in a block.
Ɣ A checkmark symbol “
” will be
displayed on the selected group.
5. Touch “Done” to end the Exception
Setting of the Run/Stop Operation
and return to the “Service Menu”
screen.
4
5
1
2
3
