JR ERGO User Manual

2-5
FRONT RADIO BED/GYRO MOUNTING PLATE INSTALLATION
2-6
COOLING FAN SHROUD INSTALLATION
13
3x18mm Set Screw
Body Mounting Standoff, Long
........2 pcs
3x10mm Socket Head Bolt
........6 pcs
........2 pcs
2.6x8mm Self Tapping Screw
........4 pcs
When installing a .46–.48 size engine,
it’s necessary to trim the bottom
portion of the Fan Shroud as shown:
Front Radio Bed
Body Mounting
Standoff, Long
3x10mm Socket
Head Bolt
2.6x8mm Self
Tapping Screw
Cooling Fan Shroud
2.6x8mm Self Tapping Screw
3x18mm Set Screw (2 pcs)
Body Mount Standoff, Long
Use Threadlock
3x10mm Socket
Head Bolt (6 pcs)
Gyro Mounting Plate
Ergo .46 Fan Shroud Adjustment
3/4"1 7/8"
Remove
Use Blue Threadlock
