4. Operation 30
4.6 Printer Control Setting
Note: JFE-380 electrically stores last 12or 24hours depth data. Optional printer runs after
only your PRINTER CONT menu PRINTER [ENT] pressing.
The following menu is displayed with [MENU]PRINTER CONT .
Setting Print Output
This item starts print function of optional printer.
Select “PRINTER” with or key. Then press the [ENT] key to start print out.
Setting Print Mode
This item selects print out mode by three items.
Select “PRINT MODE” with or key. Then press or the [ENT] key to enter the detail setting.
Detail item 㧦COPY/HISTORY/LOG
COPY
㧦
HITORY 㧦
LOG 㧦
(Refer to 4.7 communication setting.)
Select the item by or key. Then press the [ENT] key.
Note: Please read a detailed explanation of the each print mode item with next page.
PRINTER CONT
㩷 PRINTER
㩷 PRINT MODE COPY
㩷 LOG BOOK PRINT OFF
㩷 LOG LENGTH 10min
㩷 SPEED
4800bps
PRINTER MODEL SLECTION NKG-91
A present selection item is displayed with a yellow
character.
ȷTo select items, use or key to choose.
ȷPress or the [ENT] key after the item selection,
the detail setting will displayed.
Press the [ENT] key after the detail setting selection.
Then the settings would be registered and the menu
would return to previous screen.
To return to a previous screen without registering,
press or the [CLR] key.
The above-mentioned set conten
To Next Page
