10. Specifications
Display 6.5 inch TFT LCD (640 x 480 pixels)
Frequency 200kHz / 50kHz㩷 or 50kHz-A
Echo color 8 colors or 8 level monochrome
Digital depth 3 digit (0.0m to 99.9m : 0.1m steps, 100m over : 1m steps)
Range 10m 20m 50m 100m 200m 500m 800m
Sounding
capability
(Note1)
200kHz
1.0m
to
10m
1.0m
to
20m
1.5m
to
50m
2.0m
to
100m
3.0m
to
200m
5.0m
to
300m
7.0m
to
300m
50kHz
or 50kHz
-A
2.0m
to
10m
2.0m
to
20m
3.0m
to
50m
3.0m
to
100m
4.0m
to
200m
6.0m
to
500m
8.0m
to
800m
TX pulse
repetition rate
pulse per
minute
171
PPM
171
PPM
171
PPM
86
PPM
86
PPM
43
PPM
43
PPM
Accuracy
0.5m : 20m range, 5m : 200m range; or 2.5% of the indicated depth,
whichever is greater
Draft adjust 0m to 50m in 0.1m steps
Display mode Standard, History, Docking
Time range of
echo display
5, 10, 20, 30min
Auto function Gain, Range
Alarm function Depth, Power fail, System error
Preview function 12hour or 24hour
Transducers 200kHz : UT-200ND , 50kHz or 50kHz-A : UT-50MD
Power supply
100-115/200-230VAC㫧15%, 50Hz/60Hz㫧5% less than 50W
24VDC (only use for power fail monitoring)
Water proofing
Display unit : IPX5 jet proof
Connection Box : IPX2 drip proof
Input nav. data IEC61162-1NMEA0183 RMA, RMC, GGA, GLL, VTG, ZDA
Input ACK signal IEC61162-1NMEA0183 ALR
Input signals Power fail alarm ACK:
(Contact input: 12VDC 2.4mA, current control: 12VDC 1.2mA)
Depth alarm ACK, System alarm ACK:
(Contact input: 5VDC 5mA, current control: 12VDC 1.2mA)
Output depth
value data
IEC61162-1 (NMEA0183 V1.5)
IEC61162-1 (NMEA0183 V2.3)
DBS, DBT, DBK
DPT
every 1 second
every 1 second
Output alarm data IEC61162-1 (NMEA0183) ALR every 1 second
Output system
data
(IEC61162-1)
PJRCL
PJRCM (90)
PJRCM (88, 89)
UTC
UTC
every 10 seconds
every 0 to 4 hours
every 0 to 4 hours
Output PC data PJRCP
Output signals Power fail alarm, Depth alarm, System alarm:
(Relay contact output: rated load 120VAC 10A, 30VDC 8A, NO/NC)
Temperature –15°C to +55°C / operating –25°C to +70°C / storage
Humidity less than 93%RH under +40°C condition (non-condensing)
Note1: Sounding capability may vary in frequency, gain setting, bottom shape, sea state,
vessel speed, etc.
