JRC JFE-700 User Manual

4. Operation
4-4
Displaying Menu [MENU]
Displays the menu for setting various functions. To u c h button on the main screen.
Up and Down Key Cursor [CURSOR]
 When mode is a standard/history mode
・ Depth cursor is displayed according to cursor mode setting (Refer to 4.3 Display Setting-Setting Cursor
Display)
・ When the
is touched, the depth cursor is moved to shallow one.
・ When the
is touched, the depth cursor is moved to the deep end.
・ The depth of the depth cursor doesn't display below the decimal point at 100m or more.
When the depth cursor deviates from the range scale due to range changing, the depth cursor is displayed at
the bottom of the range scale.
・ When the depth cursor is displayed, tap it in the echo drawing area to move the depth cursor to that area.
・ When the key disappears, tap the screen of scale area to redisplay it.
・ Each Item are selected by touch.
・ Select the required item to display the setting menu for that item.
・ When it returns to the main screen, touch
.
Ta
p
scale are
Re-dis
p
la
y
cursor ke
y
