JRC JFE-700 User Manual

5. Maintenance & Check
5-4
5.6 Replacing Fuses
Exchange the fuse for the one of our specification. Exchange it after confirming the cause to which the fuse
is blown. Moreover, turn off the main switch of the power supply CQD-2348 when you exchange fuses
(Press ○ sign side).
No. Model type Rating Remarks
FH1 FGBO-A 250V 2A 250V 2A
For power supply in this
equipment
FH2 MF51NR 250V 0.5 or equivalent 250V 0.5A
For power supply alert circuit
in this equipment
5.7 Repair Parts
Parts name Type Code Remarks
Main Unit
CDJ-2594 CDJ2594
TX/RX Unit
CMN-869-20 CMN869-20
Single frequency for 200kHz
CMN-869-50 CMN869-50
Single frequency for 50kHz
CMN-869-22 CMN869-22
Dual frequencies for 200kHz/200kHz
CMN-869-25 CMN869-25
Dual frequencies for 200kHz/50kHz
CMN-869-55 CMN869-55 Dual frequencies for 50kHz/50kHz
Power Supply Unit
CBD-2016 CBD2016
Interface unit
CQD-2348 CQD2348
Power SW Control unit CCK-1136 CCK1136
LCD panel CCN-555 CCN555
Touch Panel Unit CCK-1710 CCK1710
Printer H-7HPJD0003 H-7HPJD0003
5.8 Regular replacement parts
Parts name Type Code
Replacement time
Remarks
LCD panel kit CCN-555 CCN555 About 40,000hours
About 5 years in continuous
use as the guideline
