9. Specifications
Display 10.4 inch TFT LCD (1024 x 768 pixels)
Frequency 200kHz / 50kHz
Echo color 8 colors or 8 level monochrome
Digital depth
3 digit (0.0m to 99.9m : 0.1m steps, 100m over : 1m steps)
Range 5m 10m 20m 50m 100m 200m 500m 800m
Sounding
capability
(Note1)
200kHz
1.0m
to 5m
1.0m
to 10m
1.0m
to 20m
1.5m
to 50m
2.0m
to 100m
3.0m
to 200m
5.0m
to 300m
7.0m
to 300m
50kHz
1.0m
to 5m
1.0m
to 10m
1.0m
to 20m
3.0m
to 50m
3.0m
to 100m
4.0m
to 200m
6.0m
to 500m
8.0m
to 800m
TX pulse
repetition rate
pulse per
minute
171
PPM
171
PPM
171
PPM
171
PPM
86
PPM
86
PPM
43
PPM
43
PPM
Accuracy
0.5m : 20m range, 5m : 200m range; or 2.5% of the indicated depth, whichever is greater
Draft adjust
0m to 50m in 0.1m steps
Display mode
Standard, History, Docking
Time range of
echo display
5, 10, 20, 30min
Auto function
Gain, Range,
Prevention interference with other ships
Alert function
Depth, Power fail, System error
Preview function Max 48hour
Transducers 200kHz : UT-200ND , 50kHz : UT-50MD
Power supply
100-115/200-230VAC±15%, 50Hz/60Hz±5% 100VAC: Max120VA, 220VAC: Max175VA
24VDC (only use for power fail monitoring) Max1.4W
Water proofing
Display processing unit : IP22 Connection Box : IP55
Input nav. data IEC61162-1NMEA0183 RMC, GGA, GLL, ZDA
Input ACK signal IEC61162-1NMEA0183 V1.5, V2.3 ACK V5.0 ACN
Input signals Power fail alert ACK:
(Contact input: 12VDC 2.4mA, current control: 12VDC 1.2mA)
Depth alert ACK, System alert ACK:
(Contact input: 5VDC 5mA, current control: 12VDC 1.2mA)
Output depth
value data
IEC61162-1 (NMEA0183 V1.5)
IEC61162-1 (NMEA0183 V2.3, V5.0)
PJRCU
DBS, DBT, DBK
DPT
every 1 second
every 1 second
every 1 second
Output alert data IEC61162-1 (NMEA0183 V1.5, V2.3)
IEC61162-1 (NMEA0183 V5.0)
ALR
ALC, ALF, ARC, HBT
every 1 second
every 1 second
Output system
data
PJRCL
PJRCM UTC
every 10 seconds
every 0 to 4 hours
Output signals Power fail alert, Depth alert, System alert:
(Relay contact output: rated load 120VAC 10A, 30VDC 8A, NO/NC)
LAN
Specification：IEC61162-450 Transmission speed：10/100Mbps
Data input/output ：NMEA,IEC,JRC format
IGMP snooping: IGMP v1, IGMPv2, IGMP v3
Temperature –15°C to +55°C / operating –25°C to +70°C / storage
Humidity less than 93%RH under +40°C condition (non-condensing)
Note1: Sounding capability may vary in frequency, gain setting, bottom shape, sea state, vessel speed,
etc.
