5. Maintenance & Check
5-2
5.3 Maintenance Function
Touch Panel Calibration
Refer to "Touch Panel Calibration" in 4.5 Initial Setting.
Displaying System No.
Refer to 4.7 Checking system version.
5.4 Replacing Printer Paper
Be careful not to cut your hands with the cutting edge of the paper cutter.
Name Model type Remarks
Printer paper H-7ZPJD0384 TF50KS-E2D for build-in printer
◎After turning off the power supply of this equipment, exchange papers.
When the printer cover is opened while turning on, the alert of “NO PAPER" sounds.
① Open the paper cover by pressing the paper cover opening button.
② Set the paper like the direction of figure.
③ Shut the cover after making the paper tip put out outside of the printer and pushing both ends of the
upper paper cover.
＊A red mark of a paper slip previous notice puts out from 1m remain when the remainder of the paper
decreases.
