JUKI TR6SNR User Manual

Maintenance Guide
8-1
8
．
Air Piping Diagram
8-1. List of air components
No.
Part No.
Part name
Place in which the part is used
1
PV150209300
5-port solenoid valve
Shuttle R-side pad selection
2
PV150209300
5-port solenoid valve
Shuttle L-side pad selection
3
PV150209300
5-port solenoid valve
Shuttle BGA L-side
4
PV150209300
5-port solenoid valve
Shuttle BGA R-side
5
PV150209300
5-port solenoid valve
Y-axis tray chuck section
6
PV150209300
5-port solenoid valve
Shutter broadening/narrowing
7
PV150209300
5-port solenoid valve
Head L-side UP/DOWN
8
PV150209300
5-port solenoid valve
Head R-side UP/DOWN
9
40045132
Ejector
Head L-side
10
40045133
Ejector
Head R-side
11
40045158
Ejector
Shuttle L-side
12
40045159
Ejector
Shuttle R-side
13
PA0402001A0
Ultra-compact air cylinder
Shuttle BGA L-side
14
PA0402001A0
Ultra-compact air cylinder
Shuttle BGA R-side
15
PA0601524A0
Y cylinder
Y-axis tray chuck section
16
PA1001024A0
Shutter cylinder
Shutter broadening/narrowing
17
PA0603004A0
Head 2 cylinder
Head L-side UP/DOWN
18
PA0603004A0
Head 1 cylinder
Head R-side UP/DOWN
19
PC012401000
Speed controller
20
PC012402000
Speed controller
21
PC010519000
Speed controller
22
PC010508000
Speed controller
23
PV010006000
Hand valve
24 40045177
Slow mode (HR UP)
cable 2 ASM
Optional: slow 2 mode
Head R-side UP
25 40045179
Slow mode (HR DOWN)
cable 2 ASM
Optional: slow 2 mode
Head R-side DOWN
26 40045181
Slow mode (HL UP)
cable 2 ASM
Optional: slow 2 mode
Head L-side UP
27 40045183
Slow mode (HL DOWN)
cable 2 ASM
Optional: slow 2 mode
Head L-side DOWN
28 40045187
Slow mode (tray)
cable 2 ASM
Optional: slow 2 mode
Y-axis tray chuck section
29 40045185
Slow mode (SHT)
cable 2 ASM
Optional: slow 2 mode
Shutter narrowing side
