Maintenance Guide
7-4
7-4. Replacement of solenoid valves for shutter and tray chuck speed reduction
(slow 2 mode: optional)
Detach the valve cover, and replace the relevant solenoid valves.
Solenoid valve Y holder (part No.: HM001780010)
Solenoid valve shutter (part No.: HM001780010)
