2 Instrument description
Event operation The digital signals can be used to activate event operation. In event operation,
the measurements are stored with a storage cycle that is different from normal
operation.
Example When the available internal memory (during read-out through the
CompactFlash memory card) falls below 1Mbyte, the storage cycle of the
measurements for group 1 should be set to 20sec.
The following have to be configured:
Parameter Value/setting
Configuration
Î Device data
Î Storage alarm
Î Int.mem./read-out via CF
1MB
Configuration
Î Group config.
Î Group 1
Î Event operation
Î Control signal
Int. mem. al./CF
Configuration
Î Group config.
Î Group 1
Î Event operation
Î Storage cycle
20[s]
