JUMO LOGOSCREEN - Page 83

83
4 Configuration parameters
Input signal
(digital channels,
group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Digital channels
➔ Digital channel
1—3
➔ Input
signal
Off,
LogInp.1 — 7,
Alarm Gr.1 — 6,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF plugged in
Stolen CF
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card
Logic inp. x
Assignment of the
hardware inputs or the
signals generated by the
software to the digital
channels of the group.
Measurement
representation
Vertical diagram
(group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Vertic.
diagram
Off,
On
If measurement
representation is Off, it
cannot be called up in
visualization.
It will be skipped
automatically when
switching measurement
representation.
Measurement
representation
Horizont. diagram
(group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Horizont.
diagram
Off,
On
Measurement
representation
Bar graph
(group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Bar graph
Off,
On
Measurement
representation
Numerical display
(group 1 — 6)
Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Numerical
display
Off,
On
Parameter Value/selection Description
