4 Configuration parameters
90
Configuration ➔ El. signature
The parameters Configuration ➔ El. signature are only active on recorders
with increased security requirements, but not on this type of recorder.
Configuration ➔ Texts
Configuration ➔ Interfaces
Parameter Value/selection Description
Texts Configuration
➔ Texts
Text 1 — 146 v Chapter 3.8 “Text entry”
Parameter Value/selection Description
20 (RS232/RS4xx) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
Setting the parameters for
the serial interface
Protocol
(20 (RS232/RS4xx))
Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Protocol
MODBUS,
JBUS
Baud rate
(20 (RS232/RS4xx))
Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Baud rate
9600 baud,
19200 baud,
38400 baud
If possible, the fastest
transfer rate should be
selected here. The next
smaller rate should only be
selected if problems arise.
Data format
(20 (RS232/RS4xx))
Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Data format
8-1-none,
8-1-odd,
8-1-even,
8-2-none
Device address
(20 (RS232/RS4xx))
Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Device address
1 —254
Min. response time
(20 (RS232/RS4xx))
Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Min. response
time
0 —500msec
21 (Profibus-DP) Configuration
➔ Interfaces
➔ 21 (Profibus-DP)
Setting the parameters for
the Profibus-DP interface.
Address
(21 (Profibus-DP))
Configuration
➔ Interfaces
➔ 21 (Profibus-DP)
➔ Address
1—125 — 127 Setting the address from
which the recorder can be
addressed in the Profibus-
DP network.
Baud rate
(21 (Profibus-DP))
Configuration
➔ Interfaces
➔ 21 (Profibus-DP)
Baud rate
The baud rate is set
automatically by the
PROFIBUS-DP master.
