7. Insert the module into the midplane by simultaneously pressing both ejectors inward

and exerting forward pressure on the module. The small red release buttons should

click into place.

8. Tighten the module's captive screws using a Phillips screwdriver.

NOTE: Tighten the captive screws completely before installing an adjacent

module so that proper electromagnetic interference (EMI) gasket

compression occurs. Failure to do this can make it difficult to install

adjacent modules.

9. Go to Cabling a CTP Interface Module.

Documentation

• Removing a CTP Interface Module, Processor Module, or Clock Module on page 89
