CHAPTER 3

System Specifications

•

CTP2008 Platform Specifications and Certification on page 31

•

CTP2024 Platform Specifications and Certification on page 33

•

CTP2056 Platform Specifications and Certification on page 34

CTP2008 Platform Specifications and Certification

Table 10: CTP2008 Platform Specifications

SpecificationCategory

Weight

16 lb (7.25 kg)Chassis only

Dimensions

1.75 in. (4.44 cm) high

17.25 in. (43.81 cm) wide

11.25 in. (28.57 cm) deep

Chassis only

Environmental Requirements

32° to 104° F (0° to 40° C)Ambient operating temperature

5% to 90% (noncondensing)Ambient operating humidity

DC Input

–40 to –72 VDCVoltage

3A @ –48 VDCCurrent

144 WPower

2 independent line feedsRedundancy (input power)

AC Input

100–240 VACPower required
