Juniper CTP2024 User Manual

Figure 31: Connecting the PP833 Processor with the RJ-45 Serial Console
4—1— Adapter from the bag labelled 720-056657PP833 front panel
5—2— RJ-45 male end of user’s console cableCable 720-071594
6—3— User’s cable that connects to the console
on a CTP150 or other Juniper product
DB-9 male end of 720-071594
Figure 32: Connecting the PP833 Processor with the PC DB-9M Serial
Console
6—1— RJ-45 male endPP833 front panel
7—2— Straight RJ-45 cableCable 720-071594
8—3— RJ-45 male endDB-9 male end of 720-071594
9—4— Adapter from the bag labelled 720-014126DB-9 female end of adapter from the bag
labelled 720-056657
10—5— DB-9 male end of PCAdapter from the bag labelled 720-056657
Related
Documentation
CTP Fast Ethernet and Power Cables on page 63•
