Table 22: DB9-to-RJ45 Adapter (p/n 450-071855) Pinouts for Connecting PP833 Processor
with Console (continued)
DB-9RJ-45
3 TXD4 GND
2 RXD5 GND
Table 23: DB9-to-RJ45 Adapter (p/n 720-056657) Pinouts to Convert PP833 Console to
CTP150 Console Pinout
DB-9RJ-45
7 RTS1 RTS
4 DTR2 DTR
3 TXD3 TXD
5 GND4 GND
2 RXD6 RXD
6 DSR7 DSR
8 CTS8 CTS
Table 24: DB9-to-RJ45 Adapter (p/n 720-014126) Pinouts for Connecting PP833 Processor
with a PC
DB-9RJ-45
8 CTS1 RTS
6 DSR2 DTR
2 RXD3 TXD
5 GND4 GND
3 TXD6 RXD
4 DTR7 DSR
7 RTS8 CTS
You can connect a console (PC, Macintosh, or UNIX workstation) directly to the COM2
port on the PP310 and PP332 processors. On the PP833 processor, a console is connected
using the supplied USB-to-DB9 cable (p/n 720-071594), in which the DB-9 connector
has the same pinout as a standard RS-232 DTE port. When the USB-to-DB9 cable is
used in conjunction with the DB-9 adapter labelled “p/n 450-071855” (see
Copyright © 2017, Juniper Networks, Inc.60
CTP2000 Hardware Documentation
