Chapter 9 Learn Geode Connect for Windows PC 119
Owner's Manual
Satellite symbols outlined in red indicate that the satellites
are being tracked, but they are not yet a part of the
positioning solution. Satellite symbols outlined in blue
indicate that a correction is being applied to the signal.
The Skyplot page is meant to be used as a guide. It shows
the relative visibility of satellites in the sky, but it is not an
absolute reference for satellites used in the positioning
solution.
Multi-GNSS Geode models support the Galileo, BeiDou,
GPS, QZSS, SBAS, and GLONASS constellations.
If the Skyplot page is not displaying data:
1. Go to the Configure Geode page by tapping the menu
icon in the navigation bar.
2. Tap Receiver Configuration.
3. Under Active GNSS Constellations, select Multi-GNSS.
4. Under NMEA Sentences, select GSV.
5. Tap the save icon .
