JVC GY-DV500U Service Manual

1-2
1.3 LAYOUTS OF THE MAJOR BOARDS
On the side of the left-hand side cover
VCR section
On the side of the bottom cover
On the side of the right-hand side cover
10DV MAIN
03ROM
16CAM2
27MIC
28BNC
38REMOTE
37SENS2
17PS1, 18PS2
19ROM 15CAM1
36SEN1
04CONN.
34MOTHER
31VIDEO/SYSCON
32AUDIO/LCD
35OPE 22SWRU 20JOG
24SWRM
25SWPB
26SWPW
21IF
23SWF
14TG
11ISB
12ISG
13ISR
42CONNECT
40XLR
43EAR.J
41PWR JUNC
39AU JUNK
01PR & MDA
02DCDC
