JVC GY-DV500U Service Manual

3-4
3.4 ADJUSTMENT MENU
3.4.1 Switches and Functions Used in Adjustments
2
3.3 STANDARD SETUP
Vectorscope
Filter 1 (3200 K)
75 Ø resistor for
termination
75 Ø resistor for
termination
Test pattern
3200 K illumination
AC adapter
(12 V DC INPUT)
Waveform monitor (WFM)
2 m or more
Color video monitor
Oscilloscope
LIGHT
ON
OFF
COUNTER
CTL
TC
UB
RESET
OPERATE/WARNING
MONITOR
SELECT
STATUSSHUTTER
MENU
FILTER
1 3200k
2 5600k
3 5600k+ND
POWER
NG
G
A
I
N
O
U
T
P
U
T
W
H
T
.
B
A
L
V
T
R
ON OFF
ALARM
MONITOR
S
A
V
E
S
T
B
Y
H
M
L
B
A
R
S
C
A
M
A
U
T
O
K
N
E
E
P
R
S
T
A
B
O
N
O
F
F
CH-1
CH-2
AUDIO
LEVEL
AUTO IRIS LOLUX
BACK L
NORMAL
SPOT L
STRETCH
NORMAL
COMPRESS
FULL AUTO BLACK
1
SW901-1 on ROM board : Set to ON (up) to display the adjustment menu on the viewfinder screen and enter the adjustment
mode.
Set to OFF (down) to turn off the adjustment menu on the viewfinder screen and exit from the adjust-
ment mode.
2
SHUTTER/MENU dial : Used to select an adjustment item, adjust the selected item and store the adjusted value in memory.
ON
12345678
ROM
S901
1
ROM BOARD
3-3
