Kaba c-lever 2662-K5 User Manual

Installation Manual Product description
11k2evo702 - 201610Kaba c-lever and variants
15 E-module 30 Silicone cushion 59 Socket for antenna cable
3.2 Scope of delivery
• 1 inside shield with internal fitting • 1 outside lever handle
• 1 outside shield • 1 antenna cable
• 1 coupling unit • 2 batteries
• 1 direction pin • 2 Allen keys, size 2 and 3
• 1 spindle • 1 set of instructions
• 1 inside lever handle • 1 drilling template
• Various fixing screws
See following table 1: Fixing screws.
3.2.1 Additional fixing screws
• 1 steel support plate for outside shield
• 1 centring sleeve
• 2 spacer sleeves
• 2 pull protection washers
• Additional fixing screws
Screw pack Top/bottom
fixing screws
Middle
fixing screws
Long arbour
mm
Dimension
mm
Door thick-
ness
mm
Dimension
mm
Door thick-
ness
mm
No. 1 105 M5 x 50 38–44 M5 x 40 38–40
M5 x 45 41–45
M5 x 60 45–54 M5 x 50 46–50
M5 x 55 51–55
M5 x 70 55–58 M5 x 60 56–58
No. 2 120
(door thick-
ness
58–73)
155
(door thick-
ness
73–100)
M5 x 70 56–64 M5 x 60 59–60
M5 x 80 65–74 M5 x 65 61–65
M5 x 70 66–70
M5 x 90 75–84 M5 x 75 71–75
M5 x 80 76–80
M5 x 100 85–94 M5 x 85 81–85
M5 x 90 86–90
M5 x 110 95–100 M5 x 95 91–95
M5 x 100 96–100
Table1: c-lever fixing screws
