Operating Instructions Powador-proLOG_EN Page 1717
6 Start-up
6.1 Procedure
1. Switch on the Powador-proLOG
Connect the supply voltage to switch on the unit. After
the supply voltage has been connected, the “Power”
LED must remain lit.
2. Check the status LEDs
The status LED provides information about the unit’s
status after it has been started up:
Status LED is off – > System is starting up
Status LED is flashing steadily – > System is ready
3. This is the most important part of start-up. Once the
system has started up (Power LED is lit/Status LED is
flashing), you should connect to the Powador-proLOG
with your computer to check whether all inverters
are answering over the RS485 line and whether all
connected sensors are providing data.
See section 7 (“Establishing a Connection”) of this
manual for information on how to connect to the Powa-
dor-proLOG with your computer.
6.2 Using the Powador-proLOG with
Powador-web
1. You do not have to configure the data logger on site.
Just make sure that the inverters and sensors are properly
connected and that the telephone/Internet connection is
working.
2. The Powador-proLOG will be configured by KACO new
energy GmbH. For this purpose, you need to fill out the
application form for Powador-web after installation is
complete. You can download the application form from
our website.www.kaco-newenergy.de
6.3 Using the Powador-proLOG without
Powador-web
1. Once you have successfully connected to the Powador-
proLOG, you should configure the unit to meet your
requirements (inverter, analogue/digital channels, alarm
notification, and data transmission).
2. You can use the “Installation Wizard” to configure and
check the measured data of the Powador-proLOG. It
will guide you through the installation process one step
at a time.
You can also use the “Profi page” to configure and
check measured data.
For more information, see section 8 (“Menu Descrip-
tion”).
3. Powador-monitor provides a graphical display for
processing measured values.
N OT E
The system needs about two minutes to be completely
initialised. This process is similar to starting up (booting)
a PC. Completion of the boot phase is indicated by the
status LED. It remains off during the boot phase, and
begins flashing once the boot phase is complete.
AT T E N T I O N
Make sure that everything is properly connected (is the
polarity correct?) and that all inverters are addressed
(RS485 address?). Be sure to read section 5 (“Installa-
tion”).
Se ction 6 · Start-up
