Page 8 Operating Instructions Powador-proLOG_EN
Se ction 4 · Technical Data
4 Technical Data
Ambient Temperatures Powador-proLOG S Powador-proLOG M/L/XL
Operation 0 °C ... + 55 °C
Storage and shipment -20 °C ... + 65 °C
Electrical Data
Powador-proLOG S Powador-proLOG M/L/XL
Power supply AC
230V / 50Hz
85V ... 260V / 47 Hz ... 63 Hz
Powar supply DC for external devices
Analogue modem
ISDN modem & Ethernet/DSL
GSM/GPRS modem
24 V / max. 210 mA
24 V / max. 240 mA
24 V / max. 170 mA
Analogue inputs (configurable)
0V ... 10V (max. 24V)
0mA ... 20mA (max. 40mA at 3V)
PT 1000 resistance measurement
Digital inputs
low = 0V ... 7V
high = 9V ... 24V
Only works with the unit’s internal power supply.
Digital output
Optocoupler output (max. load: 70V / 50mA)
Power consumption
230 V AC / approx. 7.5W - 24 V DC / approx. 2,5 W
(during measuring operation, without sensors)
Measuring accuracy
Voltage input
Current input
1 % of the end value
1 % of the end value
Interface
Analogue (PSTN)
ISDN
Ethernet (100 MBit)
GSM/GPRS (850/1900 MHz, 900/1800 MHz)
RS485
Mechanical Data Powador-proLOG S Powador-proLOG M/L/XL
Dimensions (W x H x D)
Installation
Protection rating
Weight
10 x 110 x 63mm
top hat rail mounting or wall mounting
IP 20
436g
217 x 220 x 87mm
wall mounting
IP 21
1kg
