Compressor series ASK
UASK-03070.00
ATTENTION !!!
Install supplies, grounding and shock protection
to local safety regulations.
Do not make or break
live plug-in connectors.
control cabinet wiring for non-designated conductors
with multi-standard stranded conductors
primary circuits:
Control voltage AC ungrounded:
Control voltage AC grounded:
Control voltage DC ungrounded:
Control voltage DC grounded:
external voltage:
measuring circuits:
earth conductor:
black
red 1mm² H05V-K, 18AWG UL-Style 1015, CSA-TEW
white 1mm² H05V-K, 18AWG UL-Style 1015, CSA-TEW
blue 1mm² H05V-K, 18AWG UL-Style 1015, CSA-TEW
white/blue 1mm² H05V-K, 18AWG UL-Style 1015, CSA-TEW
orange 1,5mm² H07V-K, 16AWG UL-Style 1015, CSA-TEW
violet 1mm² H05V-K, 18AWG UL-Style 1015, CSA-TEW
green/yellow H07V-K, UL-Style 1015, CSA-TEW
1 2 3 4 5 6 7 8
page
Bl.
general instructions
SC2 MCSIO
general instructions
Ersatz für:Ersatz durch:
a
b
c
Änderung
Datum
Datum
Bearbeiter
Geprüft
NormName Ursprung:
1
5
20.10.2016 =
+
C
Sitter
Büchner
