7.9 Setting the set point pressure
The system pressure pA is factory set to the highest possible value.
Adjustment is necessary for individual operating conditions.
Do not set the set point pressure of the machine higher than the maximum working pressure
of the compressed air system.
The machine may not toggle more than twice per minute between LOAD and IDLE.
To reduce the cycling (toggling) frequency:
➤ Increase the difference between cut-in and cut-out pressure.
➤ Add a larger air receiver downstream to increase buffer capacity.
➤ Set the set point pressure as described in the SIGMA CONTROL 2 operating manual.
7.10 Setting the display language
The controller can display text messages in several languages.
You can set the language for texts on the display. This setting will be retained even when the ma‐
chine is switched off.
1. In operating mode, switch to the main menu with the «Return» key.
2. Press the «UP» or «DOWN» keys until the current language is shown as active line (inverse):
6 . 1 b a r 8 0 . 0 ° C
–––––––– de_DE Deutsch ––––––––
Current language (active line)
▶1 xxxxxxxxxx
Submenu
▶2 xxxxxxxxxx
Submenu
▶3 xxxxxxxxxx
Submenu
▶4 xxxxxxxxxx
Submenu
▶5 xxxxxxxxxx
Submenu
▶6 xxxxxxxxxx
Submenu
3. Use the «Return» key to switch to setting mode.
The language display flashes.
4. Move to the required language with «UP »or «DOWN».
5. Confirm the setting with the «Enter» key.
Result The display texts are now in the selected language.
Further information Detailed information can be found in the SIGMA CONTROL 2 operating manual.
7 Initial Start-up
7.9 Setting the set point pressure
901824 12 E
Operating Manual Screw Compressor
ASK
51
