4. Slowly open the cooling water inlet shut-off valve B to gradually fill the cooler with water.
5. Bleed air from the water lines.
Further information The dimensional drawing in chapter 13.3 gives the flow direction, size and location of the connection
ports.
6.5.3 Option W1/W2/W3
Connecting the heat recovery system
➤ Take the electrochemical series into account and choose suitable materials for connections.
➤ Keep the effect of pressure surges on the heat exchanger as low as possible.
➤ Install an expansion tank to act as a pulsation damper if pressure surges cannot be avoided.
➤ Install appropriate regulating devices if the heat transfer medium is to be kept constant.
➤ Avoid very low inlet temperatures of the heat transfer medium as it can cause condensation.
If required, contactKAESER for suitable insulation measures.
WARNING
Cooling oil in the heat-receiving medium!
Oil may contaminate the medium if a leak occurs.
➤ Do not use the heat-receiving medium as drinking water.
➤ Install the heat recovery system in accordance with the following specifications.
Further information The dimensional drawing in chapter 13.3 gives the flow direction, size and location of the connection
ports.
6.5.3.1 Option W1
Connecting the external heat recovery system
An unsuitable heat exchanger or incorrect installation may adversely impact the cooling oil cir‐
cuit within the compressor. Damage to the machine will follow.
➤ Consult with KAESER on a suitable heat exchanger and have an authorized KAESER Service
do the installation.
6 Installation
6.5 Options
40
Service Manual Screw Compressor
BSD 9_5708 08 USE
