KAESER BSD 50 User Manual

Fig. 17 Label: Changing the display language
1 If required:
Unlatch the EMERGENCY STOP button.
2 If required:
Acknowledge alarm message.
3 Depress the «escape» key for 5 seconds to
change to the main menu.
4 Press the «UP» key 8 times.
5 Press «Enter» to enter language selection.
6 Press the «UP» or «DOWN» keys as often
as necessary to reach the required lan‐
guage.
7 Press «enter» to select the language.
8 Depress the «escape» key for 5 seconds to
change to the main menu.
➤ Change the display language on SIGMA CONTROL as required.
7 Initial Start-up
7.10 Changing the display language
9_5708 08 USE
Service Manual Screw Compressor
BSD
47

KAESER BSD 50 Specifications

General

Model	BSD 50
Category	Rotary Screw Compressor
Motor Power	30 kW
Noise Level	69 dB(A)
Drive Type	Direct
