3. Shut down the machine.
4.
Wait until the machine has automatically vented.
Pressure gauge reads 0 bar.
5. Open the outlet valves.
6. Check the oil level after about 5 minutes.
Top up if necessary.
7. Carry out a visual check for leaks.
10.4.5 Changing the oil separator cartridge
The oil separator cartridge cannot be cleaned.
The life of the oil separator cartridge is influenced by:
■ Contamination in the air drawn into the compressor
■ and adherence to the changing intervals for:
─ Cooling oil
─ Oil filter
─ Air filter
Material Spares
Cleaning cloths
Precondition The machine is shut down.
The machine is fully vented, the pressure gauge reads 0 bar.
Machine cooled down.
All compressed air consumers are disconnected and the air outlet valves are open.
The negative cable to the battery is disconnected.
10 Maintenance
10.4 Compressor
No.: 9_9432 02 E
Service Manual Screw Compressor
M43
93
