2.3.4 Dimensions
For specifications according to the machine's operating licence, such as:
■
dimensions,
■ track width,
■ footprint,
see the dimensional drawings in chapter 13.3.
2.4 Chassis
2.4.1 Weights
Maximum weights are shown. Actual weights of individual machines are dependent on equip‐
ment fitted (see machine nameplate).
Feature 01 02 03 04
Chassis type EU
chassis
EU
chassis
EU
chassis
EU
chassis
Height-adjustable towbar x x − −
Fixed height towbar − − x x
Parking brake − x x x
Service brake − x − x
Actual total weight [kg]*
Permissible axle load [kg] 750 850 750 850
x ≙ available, − ≙ not available
EU ≙ Europe
* Enter here the actual overall weight from the nameplate as reference,
Tab. 20 Machine weights
2.4.2 Tyres
Characteristic/marking
Tyre size 145/80 R 13
Maximum and recommended tyre pressure [bar] 3,0
Wheel bolts M 12 x 1,5
Tab. 21 Tyres
2.4.3 Wheel fixing tightening torque
Market Fixing medium Thread Wrench size Torque [Nm]
Europe Wheel bolt M 12 x 1,5 19 90
USA Wheel bolt M 12 x 1,5 13/16” 100
Tab. 22 Wheel fixing tightening torque
