KAESER M43 - 2.5 Compressor

2.5 Compressor
2.5.1 Working pressure and FAD
Maximum working pressure [bar] 7
SIGMA airend 190
Free air delivery [m
3
/min]
4,2
Tab. 23 Working pressure and FAD
2.5.2 Compressed air outlet
Discharge valve ["] No.
G 3/4 2
*G 1 1
*Optional
Tab. 24 Compressed air distributor
2.5.3 Pressure relief valve
Further information Maximum working pressure: see nameplate
Maximum working pressure [bar] 7
Relief valve activating pressure* [bar] 9,5
*The pressure relief valve is fitted to the oil separator tank.
Tab. 25 Relief valve activating pressure
2.5.4 Temperature
Machine temperatures Values
Recommended airend discharge temperature for
switching to load [°C]
30
Typical airend discharge temperature during opera‐
tion [°C]
75 – 100
Maximum airend discharge temperature (automatic
safety shut-down) [°C]
115
Tab. 26 Machine temperatures
2.5.5 Cooling oil recommendation
A sticker showing the type of oil used is located near the oil separator tank filler.
Information on ordering cooling oil is found in chapter
11.
