KAESER M43 - 4.2 Component identification

4.2 Component identification
Fig. 3 Side view (canopy removed)
1 Instrument panel
2 Oil separator tank
3 Fuel tank
4 Oil cooler
5 Battery
6 Canopy safety catch lock
7 Coolant expansion tank
8 Radiator
9 Engine
10 Compressor air filter
11 Inlet valve
12 Airend
13 Compressed air outlet valve
14 Pressure relief valve
15 Thermostatic valve
16 Engine fan
17 Lifting eye
4 Design and Function
4.2 Component identification
No.: 9_9432 02 E
Service Manual Screw Compressor
M43
25
