KCI ActiV.A.C. - Carrying Case and Clinician Mode; Inserting the Therapy Unit into the Carrying Case

Canister Change (in Carrying Case) cont.
8 Grasp the ActiV.A.C. Therapy Unit in one
hand and turn the unit and case so that the
canister is facing up. Continue to fold the
Access Flap back until the is
.
See pictures and .
®
.
canister fully
exposed
8a
8b
9a
9b
9
Press the Canister Latch Release and
remove the canister from the therapy unit.
ActiV.A.C. Therapy Unit so that
the Canister Latch Release can be pressed
toward the 50ml graduation mark.
See picture .
See pictures and .
®
. Position the
9a
9a 9b
10a 10b
10. Install the new canister onto the ActiV.A.C.
Therapy Unit by sliding the opening in the
canister over the Canister Latch Guide. Do
not twist or turn the canister as it is being
installed. See picture
Push the canister onto the therapy unit. An
audible “click” should be heard.
See picture .
®
.
10a
10b
Ensure that no part of the case is
between the canister and the
ActiV.A.C. Therapy Unit.
®
11. Ensure the canister is securely installed on
the therapy unit. If the canister is properly
installed, the canister cannot be removed by
gently pulling the canister directly away from
the therapy unit.
8a
Canister
8b
Canister
12. Pull the Access Flap back over the
canister and ActiV.A.C. Therapy Unit so
that the canister is covered by the case.
See pictures and .
®
12a
12b
12a
Access
Flap
12b
Dispose of the canister according to
institution and local environmental
regulations.
