KCI ActiV.A.C. - Canister Change (in Carrying Case)

(1.)
(2.)
4
2
1
Front Flap
3
Canister Change (in Carrying Case)
Do not turn power off to the Therapy Unit.ActiV.A.C.
®
4. Disconnect the dressing tubing from the canister tubing by:
(1.) twisting the tubing connectors until the locking tabs are
disengaged,
(2.) pulling the connector apart. See picture .
4
5
5. Close the Front Flap and turn the ActiV.A.C. Therapy Unit over so
that its Front Flap is facing down. See picture .
®
5
6
Remove the tubing from the Tubing Storage Pocket.
6. Unzip the Tubing Storage Pocket Zipper. See picture .
6
7
7. Unzip the Center Zipper on the back of the case. Undo the Hook
and Loop Fastener on the Access Flap and fold the Access Flap
back to begin to expose the canister. See picture .
7
2 Slide both tubing clamps toward the tubing connector. . See
picture .
2
1. Open the Front Flap on the Carrying Case. See picture .
f addressing a Canister
Full Alarm.
Stop V.A.C. Therapy by pressing on the Touch Screen
User Interface. See picture .
V.A.C. Therapy is already off i
®
®
On/Off
1
1
3. Tightly close both tubing clamps. (Several clicks should be heard).
See picture .
3
