10.4” LVDS display features
The LCD 10.4” LVDS module has a maximum resolution of 800x600,
by two fluorescent lamps, brightness is adjusted in the setup.
10.4” display features
Dimensions 10.4”
Technology LVDSx
Visible area 211.2 (A) x 158.4 (L) mm
Resolution 800 x 600
Colours 262144
Dot Pitch 0.264 mm
Brightness 400 cd / m² typical
Horizontal visual angle
(left + right)
120° typical
Vertical visual angle
(high + low)
100° typical
Contrast value on optimal angle 450:1 typical
Response (Rise) 8 ms maximum
Response (decay) 17 ms maximum
Power supply 3.3 V
Surface finish Anti-glare
Backlit Two CCFL (Cold Cathode Fluorescent Lamp)
