General description
Karl E. Brinkmann GmbH 23
17.0”Display features
The LCD 17.0” module has a maximum resolution of 1280x1024, ac-
tive matrix backlit by four fluorescent lamps
Brightness is adjusted in the setup.
Display features 17.0”
Dimensions 17,0”
Technology LCD-TFT active matrix
Visible area 337.92 (A) x 270.336 (L) mm
Resolution 1280 x 1024
Colours 16M
Dot Pitch 0.264 mm
Brightness 300 cd / m² typical
Horizontal visual angle
(left + right)
160° typical
Vertical visual angle
(high + low)
160° typical
Contrast value on optimal angle 1000:1 typical
Response (Rise) 3,7 ms maximum
Power supply 5 V
Surface finish Anti-glare
Backlit 4 CCFL (Cold Cathod Fluorescent Lamp)
Life cycle of lamps 50000 hours
