User's manual – C6 ECON
48 Karl E. Brinkmann GmbH
Cooling
On the rear compartment and on the body of the display, there are
holes that allow air circulation through natural convection inside the
system. The unit is designed to be installed vertically.
NB: Be sure not to obstruct the ventilation openings. Periodi-
cally clean the filters as explained below for the version with
forced ventilation.
detail of C6 ECON ventilation holes with internal PCI slot
detail of C6 ECON ventilation holes with internal PCI slot
Cool air intake
Cool air intake
Cool air intake
Cool air intake
