User's manual – C6 ECON
28 Karl E. Brinkmann GmbH
Technical data
Power supplies
Nominal input voltage 24V
Input voltage range 18-36V
Max. current input 1.7 A
Nominal output voltage 12V
Nominal output current 2.5 A
Activation threshold Approximately 16V
Protections on power supply Welded internal fuse F4 A on input
Batteries
Type 2 cells lead Cyclon D 5 Ah
Charge Rapid: Constant current 3 A
Backup: Constant voltage 5V
Duration at nominal charge *15 min. at 25°C with fresh, charged batteries
Duration in backup 10 years at 25°C
4 years at 35°C
1 year at 50°C
*Backup time depends on machine configuration (type of display,
add-on modules, etc.) with fully charged batteries.
Protections on batteries
Type Welded internal fuse F15 A
Interruption of rapid charging at low (< 5 °C) and high (>65 °C) tem-
peratures
Automatic release of batteries at end of discharge
Mechanics
Dimensions 235 x 65 x 50 mm ( L x H x S )
Weight 1200 g. approx.
Assembly On back of machine C6 ECON or immediately nearby us-
ing the extension cord (optional) of 1 m
Connections
Connections Shielded cable of approximately 20 cm with connector
DB15 on the end
