General description
Karl E. Brinkmann GmbH 9
Serial interface 1 x RS-232 (DB9)
Ethernet 2 x 10/100 Mbps (RJ45)
Keyboard/mouse interface 1 x Minidin PS/2 with uncoupler
Interface USB (2.0) 1 on front panel
1 internal available on motherboard
4 connectors located on back of machine
Expansion slots 1 internal PCI slot (optional)
1 module PC/104 Plus internal*
(see paragraph on expandability configuration in the
chapter on general description)
Mass memory interfaces 1 x SATA/150, 1 x PATA/100 (used by Compact
Flash), 1 slot Compact Flash type II with external
access
Power supply 18-36 VDC (3.00A @ 18V – 1.50A @ 36V)
at maximum load (**)
Consumption C6 ECON 54W
C6 ECON (Box) 34W
Relative humidity maximum 80% without condensation
Storage temperature -20°C ÷ +60°C
Operative temperature for C6
ECON without hard disk with
LCD 8.4”, 10.4”, 12.1”, 15.0”
and C6 ECON
0°C ÷ 50°C
Operative temperature for C6
ECON without hard disk with
LCD 17.0”
0°C ÷ 45°C
(estimated increased power 5W)
Operative temperature for C6
ECON with hard disk with
LCD 8.4”, 10.4”, 12.1”, 15.0”,
17.0”
0°C ÷ 45°C
(estimated increased power 8W)
(*) Use of the internal PCI slot precludes the use of add-on such as
PC/104Plus.
(**) with LCD 15.0”, without hard disk, add-on 3W.
