Parameter sets

Fr.04 Parameter set setting

Parameter Fr.04 can be written via keyboard and via bus. The desired parameter set (0…7) is directly preset

as value and activated by pressing Enter.

Fr.07 Select inputs for paraset.

The setting for the terminal strip can be done binary-coded or input-coded. The inputs are determined with

parameter Fr.07. Maximally three inputs should be programmed to set source at binary-coded set source, in

order to avoid set source errors.

Fr.10: Parameter set input selection

Bit Value Input Terminal

0 1

ST (prog. input „control release/reset“) X2A.12

1 2 RST (prog. input „reset“) no

2 4 F (prog. input „forward“) no

3 8 R (prog. input „reverse“) no

4 16 I1 (prog. input 1) X2A.13

5 32 I2 (prog. input 2) X2A.14

6 64 I3 (prog. input 3) X2A.15

7 128

I4 (prog. input 4) X2A.16

8 256 IA (internal input A) no

9 512 IB (internal input B) no

10 1024 IC (internal input C) no

11 2048 ID (internal input D) no

Input ST is assigned by hardware with the function „control release“. Further functions can only be ad-

justed additionally.

The input I4 is connected by hardware with the master- / slave control. Further functions can only be

adjusted additionally.
